APPLICATIONS

• Highly productive MIG/MAG and advanced MMA welding.
 Suitable for Aluminium, Stainless Steel, Mild Steel and Cored Wire.
• Typical market segments:
- General Industrial Fabrication
- Energy Generation
- Windmills
- Trucks Busses and Trailers
- Trains & Railway Cars
- Earthmoving and Mining Equipment
- Mobile Machinery
- Steel Sections
- Shipbuilding/Offshore

SPECIFICATION

Mains Voltage, V - 380–460
Number of Phases, ph -  3
Supply Frequency, Hz - 50/60
Fuse Slow, A - 20
Welding Output A/V
100% duty cycle - 300/29
60% duty cycle - 400/34
Setting range A
MIG/MAG - 16-400
MMA -  16-400
TIG - 4-400
Open Circuit Voltage, V - 55
Open Circuit Voltage VRD, V - <35
Rated kVA -          25.2
Energy Save Mode, W - 40
Efficiency at Max Current % - 89.5
Power Factor at Max Current - 0.95
Dimensions L x W x H, mm -  610 x 250 x 445
Operating Temperature, °C - 10 to +40
Recommended Mains Cable Cross Section - AWG 10, (4x 4,0 mm2)
